Model A56 1.5" F x M (no hydrovent)

Model A56, 1½" 38mm (female x male outlet, no hydrovent)

Application: Used with S-4 stationary pin racks, reels trays and hangers for direct connection onto valve.
Construction: Forged Brass body with red handwheel.
Rated Pressure: 300 psi / 2068.50 kpa.
Approvals: ULC (CE x589), UL (618R) FM Approved

Optional Finishes:

A56B - Rough Brass         A56C – Rough Chrome
A56PB – Polished Brass   A56PC – Polished Chrome

For full product information please click on the PDF link under the image.
