A86 Straight Globe Hose Valves
Casted bronze globe hose valve, straight pattern for the control of the flow of water from a pipe out to the valve and usually along a standpipe riser. Turning the handle of the hose valve allows the water to flow out from the valve, or shuts it off to prevent any more water from running out. It is used with a Fire Hose Rack Assembly, or as a Fire Department outlet connection. 2 1/2” NPT inlet and 2 1/2” Female NPT outlet (A85) or 2 1/2”male hose thread outlet (A86). 175 lbs rated. With red handweel.
Product specifications
Straight Globe Hose Valve, used with fire hose rack assembling or as Fire Department outlet connection with main feature as following:- Casted bronze body- Forged brass shutter- 2 1/2” female NPT inlet - 2 1/2” male hose thread outlet- Aluminum red painted hand wheel- Rated pressure 175 psi- UL-ULC listed
Approvals: A85 and A86 LISTED 618R CE x 589 175 PSI Certified as pressure restricting valve with shut off feature
