General Air Products Air Compressors

Oil Less Riser Mounted Air Compressors
for Fire Sprinkler Systems

General's oil less riser mounted air compressors are fully automatic, and virtually maintenance free. OL Series riser mounted compressors are designed to be easily installed either vertically or horizontally to the riser. Units may be installed as air maintenance compressors. All units are UL 2125 Listed. Standard motors are single phase. Three Phase and 50 Hz units are available - consult factory.

OL Series Riser Units Standard Features Include:

• UL 2125 Listed
• Universal Riser Mounting Kit
• UL Listed Pressure Switch
• Bubble Tight Air Check Valve
• Oil Less Piston Compressor
• Customer Service and Technical Support

General Arrangement Drawings

OL Series Model	System Capacity	Motor HP
OL11016AC	110	1/6
OL21533AC	215	1/3
OL33550AC	335	1/2
OL435V75AC	435	3/4
OL610V100AC	610	1
OL900V100AC	900	1
OL1200V200AC	1200	2
